Wintop’s industrial switches and optical transceiver product lines cover every stage from substations to distribution networks. Designed for wide-temperature operation, they deliver high reliability and stable performance. We tailor solutions to your needs to help you meet the toughest environmental challenges.
RS6310-2GF8GT-GY is a rail-mount managed industrial-grade Ethernet switch, providing 2 Gigabit optical ports and 8 Gigabit electrical ports, adopting fanless, low-power consumption, industrial Level 4 design, with IP40 protection rating. It features an operating temperature of -40 ~ 85°C, ultra-strong ruggedness, specifically designed for network communications in harsh application environments, with high EMS protection capability, and every product has undergone 100% burn-in testing to ensure quality. Supports functions such as STP/RSTP, 802.1Q VLAN, port mirroring, storm suppression, MAC address query, etc.; supports port configuration, port statistics, quick DIP switch configuration, port alarm, remote reboot, factory reset, file management upgrade/download, etc.; supports WEB access methods. The management system interface is user-friendly, simple and convenient to operate, providing you with a great user experience.
Product Technical Specifications
| Standards Supported | |||
| IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX and 100Base-FX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-LX and 1000Base-SX, IEEE 802.3x Flow Control, IEEE 802.1d STP Protocol, IEEE 802.1w RSTP Protocol, IEEE 802.1Q VLAN | |||
| Backplane Bandwidth | 20Gbps | Packet Forwarding Rate | 15Mpps |
| VLAN Range | 1-4094 | MAC Address Table | 4K |
| Optical Ports | 100/1000Mbps | Ethernet Ports | 10/100/1000Mbps Adaptive, Full/Half Duplex Mode, supports MDI/MDI-X. |
| LED Indicators | P1, P2, RUN, L/A | Input Voltage | DC9~48V (Redundant) |
| Full Load Power Consumption | 5.2W | Housing | Aluminum Shell, IP40 Protection |
| Dimensions | 142 × 116 × 51mm | Weight | 850g |
| Mounting | DIN Rail | Operating Temperature | -40 ~ 85°C (-40 ~ 185°F) |
| Storage Temperature | -40 ~ 85°C (-40 ~ 185°F) | Relative Humidity | 5 ~ 95% (Non-condensing) |
| Electromagnetic Immunity (EMS) | |||
| IEC61000-4-2 (ESD) Level 4 (±15kV air discharge, ±8kV contact discharge), IEC 61000-4-5 (Surge) Level 4 (6kV port lightning protection, 4kV power lightning protection) | |||
| Vibration Resistance | IEC 60068-2-6 | Shock Resistance | IEC 60068-2-27 |
| Free Fall | IEC 60068-2-32 | Certifications | CE, FCC, RoHS, MIIT Network Access License, Ministry of Public Security Inspection Report |
| MTBF (Mean Time Between Failures) | 500,000 h | Quality Assurance | 5 Years |
About the manufacturer, Wintop
R&D Capabilities
Wintop operates a 10,000-square-foot R&D center and has accumulated over 60 technology and invention patents, establishing a comprehensive intellectual property system.
Performance Testing
Every product from Wintop Photoelectric undergoes comprehensive testing on professional communication equipment testing platforms to ensure the solutions operate efficiently and stably in real-world application environments.
Quality Management
Stringent quality management and high-standard material control systems ensure high-quality, highly stable products.
Wintop products are manufactured in compliance with stringent quality standards.
If you cannot find a relevant solution, please contact us
Please ensure the device is securely placed to prevent falling or strong vibrations. Use a power supply that meets the required specifications. Avoid operating the device in damp, dusty, or environments with strong electromagnetic interference. Do not open the device casing during operation. When cleaning, disconnect the power first and use a dry, soft cloth. The interfaces support hot-plugging, but please ensure standard cables and modules are used.
If you discover potential or actual security vulnerabilities related to Wintop Photoelectric products or identify security issues on Wintop Photoelectric external websites, please send the relevant information to our dedicated security incident response team email. Our professional security experts will promptly investigate and address the matter, while strictly maintaining the confidentiality of your identity and information.
Choosing Wintop maintenance services means choosing peace of mind. We remain committed to our service philosophy of efficiency, speed, professionalism, and comprehensiveness, providing comprehensive repair and maintenance services for your equipment to support your business growth. No matter what type of repair or maintenance service you require, Wintop Photoelectric is dedicated to delivering high-quality, convenient, and worry-free solutions, ensuring your complete satisfaction and peace of mind.
RS6310-2GF8GT-GY Layer 2 DIN-Rail Managed Switch
Rail-Mount Managed Industrial Ethernet Switch with 2 Gigabit Optical Ports and 8 Gigabit Electrical Ports
