Wintop’s industrial switches and optical transceiver product lines cover every stage from substations to distribution networks. Designed for wide-temperature operation, they deliver high reliability and stable performance. We tailor solutions to your needs to help you meet the toughest environmental challenges.
The wintop RS2310-1GF9GT-8POE is an industrial-grade wide-temperature Ethernet switch developed by wintop to meet the requirements of industries such as intelligent transportation, highways, smart cities, safe cities, new energy, and intelligent manufacturing. The product features one Gigabit uplink SFP slot, one Gigabit uplink RJ45 port, and eight Gigabit PoE downlink RJ45 ports, delivering high-speed packet forwarding and ample backplane bandwidth to ensure clear and smooth image transmission.
Equipped with an IP40-rated aluminum housing, vibration-resistant DIN-rail mounting, operating temperature range of -40°C to +85°C, and excellent EMC performance, this series provides stable and reliable operation in harsh industrial environments.
Product Technical Specifications
| Standards Compliance | |||
| IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3z 1000Base-X, IEEE 802.3ab 1000Base-T, IEEE 802.3af/at PoE | |||
| Backplane Bandwidth | 20 Gbps | Packet Forwarding Rate | 15 Mpps |
| MAC Address Table | 4K | SFP Port | 1000 Mbps (LC Interface) |
| RJ45 Ports | 10/100/1000 Mbps Auto-Negotiation, Full/Half Duplex Mode, Support MDI/MDI-X | LED Indicators | P1, P2, L/A, PoE |
| Input Voltage | DC 48~57V (Redundant) | Full Load Power Consumption | 7W (Excluding PoE), 120W (Including PoE) |
| Enclosure | Aluminum Housing, IP40 Protection | Dimensions | 142 x 116 x 51 mm |
| Weight | 850 g | Mounting | DIN-Rail |
| Operating Temperature | -40 ~ 85°C (-40 ~ 185°F) | Storage Temperature | -40 ~ 85°C (-40 ~ 185°F) |
| Relative Humidity | 5 ~ 95% (Non-Condensing) | ||
| Electromagnetic Susceptibility (EMS) | |||
| IEC 61000-4-2 (ESD) Level 4, IEC 61000-4-4 (EFT) Level 4, IEC 61000-4-5 (Surge) Level 4 (4 kV Port Surge Protection, 4 kV Power Surge Protection) | |||
| Vibration Resistance | IEC 60068-2-6 | Shock Resistance | IEC 60068-2-27 |
| Free Fall Resistance | IEC 60068-2-32 | Certifications | CE, FCC, RoHS, MIIT Network Access License, Public Security Inspection Report |
| MTBF (Mean Time Between Failures) | 500,000 h | Warranty | 5 Years |
About the manufacturer, Wintop
R&D Capabilities
Wintop operates a 10,000-square-foot R&D center and has accumulated over 60 technology and invention patents, establishing a comprehensive intellectual property system.
Performance Testing
Every product from Wintop Photoelectric undergoes comprehensive testing on professional communication equipment testing platforms to ensure the solutions operate efficiently and stably in real-world application environments.
Quality Management
Stringent quality management and high-standard material control systems ensure high-quality, highly stable products.
Wintop products are manufactured in compliance with stringent quality standards.
If you cannot find a relevant solution, please contact us
Please ensure the device is securely placed to prevent falling or strong vibrations. Use a power supply that meets the required specifications. Avoid operating the device in damp, dusty, or environments with strong electromagnetic interference. Do not open the device casing during operation. When cleaning, disconnect the power first and use a dry, soft cloth. The interfaces support hot-plugging, but please ensure standard cables and modules are used.
If you discover potential or actual security vulnerabilities related to Wintop Photoelectric products or identify security issues on Wintop Photoelectric external websites, please send the relevant information to our dedicated security incident response team email. Our professional security experts will promptly investigate and address the matter, while strictly maintaining the confidentiality of your identity and information.
Choosing Wintop maintenance services means choosing peace of mind. We remain committed to our service philosophy of efficiency, speed, professionalism, and comprehensiveness, providing comprehensive repair and maintenance services for your equipment to support your business growth. No matter what type of repair or maintenance service you require, Wintop Photoelectric is dedicated to delivering high-quality, convenient, and worry-free solutions, ensuring your complete satisfaction and peace of mind.
RS2310-1GF9GT-8POE Smart DIP-Switch PoE Switch
10-Port PoE Industrial Ethernet Switch, with 1 Gigabit SFP Port, 1 Gigabit RJ45 Port, and 8 Gigabit PoE RJ45 Ports
